To adjust the diameter of a laser

Laser Beam Expanders

High performance Laser Beam Expanders, realized by combining lens design techniques with anti-reflective coating technology.

Overview

We have a diverse lineup, including those for fundamental waves of Fiber Laser and YAG Laser, SHG and THG, fixed magnification and zoom type.

Features & Strengths

Point1 Low wave front error design

Point2 Very compact size, all fixed beam expanders use the same housing

Point3 Easy to adjust for beam divergence

Applications


Laser marking

Laser marking, a technique for writing letters, symbols, and bar codes without ink.
Our lenses can be utilized in optical systems for laser scanning.


Laser processing

Lasers offer increasingly high output. They can be used for engraving, cutting, drilling, melting, 3D modeling and many other processes.
Depending on the application, the performance required of optical systems also varies. We will propose and design the optimum lens for your needs.

Specifications

Laser Beam Expanders

Optical system used when expanding the input laser beam to have its collimated beam.

  • Diverse lineup from x1.5 to x10
  • Easy to change the expansion ratio by replacing beam expanders with minimal alignment.
Scrollable
Wavelength Expansion ratio Product name Housing size Maximum input beam diameter Maximum output beam diameter Total Transmission
1064nm (BK7) x1.5 EXP-1.5W φ25 x 63.8mm φ8.0mm φ12.0mm over 96%
x2 EXP-2W φ25 x 63.4mm φ8.0mm φ16.0mm
x3 EXP-3W φ25 x 62.4mm φ6.0mm φ18.0mm
x4 EXP-4W φ25 x 63.5mm φ4.5mm φ18.0mm
x6 EXP-6 φ25 x 63.5mm φ3.0mm φ18.0mm
x8 EXP-8 φ25 x 65.0mm φ2.0mm φ16.0mm
x10 EXP-10 φ25 x 64.8mm φ1.8mm φ18.0mm
1064nm (fused silica) x2 EXP-2FSL φ25 x 62.7mm φ8.5mm φ17.0mm
532nm (BK7) x1.5 EXP-1.5W φ25 x 62.7mm φ8.0mm φ12.0mm
x2 EXP-2W φ25 x 62.5mm φ8.0mm φ16.0mm
x3 EXP-3W φ25 x 61.2mm φ6.0mm φ18.0mm
x4 EXP-4W φ25 x 62.3mm φ4.5mm φ18.0mm
x6 EXP(SHG)-6 φ25 x 62.2mm φ3.0mm φ18.0mm
x8 EXP(SHG)-8 φ25 x 63.8mm φ2.0mm φ16.0mm
x10 EXP(SHG)-10 φ25 x 63.9mm φ1.8mm φ18.0mm
532nm (fused silica) x2 EXP-2FSL φ25 x 61.6mm φ8.5mm φ17.0mm
355nm (fused silica) x3 EXP(THG)-3 φ25 x 63.8mm φ6.0mm φ18.0mm
x4 EXP(THG)-4 φ25 x 63.6mm φ4.5mm φ18.0mm
x6 EXP(THG)-6 φ25 x 63.7mm φ3.0mm φ18.0mm
x8 EXP(THG)-8 φ25 x 63.3mm φ2.0mm φ16.0mm
x10 EXP(THG)-10 φ25 x 63.9mm φ1.8mm φ18.0mm

*The specifications and measurements listed are design values.

*Specifications may change with product improvements.

*We can also design customized optics that meet your requirements.
Please feel free to contact us.

Zoom-type Laser Beam Expanders

Optical system used when expanding the input laser beam to have its collimated beam.

  • After adjusting focus, expansion ratio can be set linearly without change in housing length.
  • Easy to change the expansion ratio by replacing beam expanders with minimal alignment.
Scrollable
Wavelength Expansion ratio Product name Housing size Maximum input beam diameter Maximum output beam diameter Total Transmission
1064nm (Optical Glass) x1 to x3 EPZ-13C φ25 x 58±3mm φ8(x1) to φ3.5(x3) φ8(x1) to φ10.5(x3) over 96%
x3 to x7 EPZ-37C φ25 x 58(+3/-0.6)mm φ4.5(x3) to φ1.8(x7) φ13.5(x3) to φ12.6(x7)
1064nm (fused silica) x0.8 to x3 EPZ-13S φ25 x 64(+3/-0.6)mm φ4 φ12
x3 to x7 EPZ-37S φ25 x 64(+3/-0.6)mm φ3.0(x3) to φ2.2(x7) φ9.0(x3) to φ15.4(x7)

*The specifications and measurements listed are design values.

*Specifications may change with product improvements.

*We can also design customized optics that meet your requirements.
Please feel free to contact us.
